ZF Marine propulsion systems launches the ZF W10000

ZF Marine Propulsion proudly introduces the new workboat transmission family ZF W10000, enhancing the range of ToughGear series transmissions.

The brand new ZF W10000 transmission, introduced at the 2014 SMM show in Hamburg, is the latest commercial vessel transmission from ZF Marine, a world leader in marine propulsion system technology.

This new family of transmissions is designed specifically for the commercial craft segment. “We spent a lot of time talking to the market, but more importantly, listening to the market,” said ZF Marine's André Körner, Head of Product Line, Commercial and Fast Craft. “The W10000 is the direct result of market feedback.”

Designed predominantly for the offshore and tugboat markets, the W10000 is rated to 2610kW (3500hp) at 2100rpm.

The W10000’s new compact design increases power density compared to the current offerings in this range. It represents a transmission family of a new generation based on ZF’s standardized platform for component sharing. This will reduce complexity and increase service parts availability across various product families.

The new transmission is available at launch with ratios from 2.0:1 up to 7.9:1. “Here also we responded to market demand,” said Mr. Körner. “Our customers are requesting deeper ratios and the W10000 delivers.” The transmission can be ordered in reversing, non-reversing, and hybrid-ready (PTI) versions. W10000 transmissions also incorporate an integrated shaft brake, a powerful 1000kW (1340hp) Top PTO, and many accessories including ZF Autotroll, available for various applications and vessels with dynamic positioning requirements.

SMM 2014 also marks the launch of the new ToughGear brand from ZF Marine. ToughGear represents the ZF "W" series transmissions, designed from the ground up for the most rigorous duty cycles in the most challenging environments.

“For many years ZF has been supplying transmissions to the workboat market,” said André Körner. “We see that people will repower vessels, yet the ZF transmission remains in place dutifully turning engine power into thrust. Many times operating in seriously challenging environments. Time and again our customers tell us, 'I run my vessel hard, and these ZF transmissions are some really tough gears.' It was time for ZF to give our 'W' series transmissions the recognition they deserve.”

This article was originally published on Marine & Industrial Report newspaper Vol 36  No.5  Issue last October 31, 2014.
